High Pressure Fittings
Avlok is an established high pressure fittings manufacturer and supplier which are designed for applications in highly demanding environments and found in the sectors of oil and gas, petrochemical, and power generation, among others. Specifically, designed for applications where high pressures come into play, We ensures reliable and safe connections.
Our available high pressure fitting types hose, pipe, compression, hydraulic, grease . These fittings are well manufactured to ensure consistent performance even under extreme conditions. Our stainless steel high-pressure fittings with flexible end connections, such as NPT, BSP, and BSPT, are designed to be compatible with any piping system, adhering to global quality standards.
Specification
Manufacturer of: High Pressure Hydraulic Hose Fittings, Adapters, Couplers
Pressure Ratings: Up to 22 500 psig (1551 bar), Over 20k to 60k PSI – (414MPa)
Temperature Ratings:
- Up to 1000°F (537°C)
- -423ºF (-252ºC ) to 1200ºF (649ºC)
Tubing sizes: 1/4″, 5/16″, 3/8″, 9/16″, and 1″.
Connection type: Coned-and-threaded connection
Materials of construction: 316 Stainless Steel, Super Duplex Alloy 2507, Inconel Alloy 625
End Connections: PIPE METRIC, NB, BSP, NPT, BSPT, Socket weld & Screwed
Types: NPT, medium-pressure cone and thread adapters, male SAE/MS
Size Range: 1/4, 3/8, 1/2, 9/16, 3/4, 1 in.; 6, 10, 12 mm (1 in. only available in 316SS)
High Pressure Hose Fittings
RECOMMENDED MAXIMUM SERVICE TEMPERATUES FOR AUSTENITIC STEEL & OTHER MATERIALS IN DRY AIR.
| MATERIAL GRADE | EG F | EG C |
|---|---|---|
| Inconel 600 | 2150 | 1175 |
| Inconel 625 | 1800 | 980 |
| Hastelloy C276 | 800 | 427 |
| 1/8” | 10000 | 6500 |
| SS 304L | 1500 | 816 |
| SS 316L | 1500 | 816 |
| MONEL 400 | 800 | 427 |
| BRONZE | 450 | 230 |
| BRASS | 450 | 230 |
| COPPER | 400 | 202 |
High Pressure Pipe Fittings
high pressure hoses and fittings components that can easily handle extreme pressure levels. Cones as well as threaded products that can be withstood under the high pressure are the main product types. In hydraulic applications, hose fittings at high pressure are common; they have to be flexible so as to maintain flexibility for dynamic movements in the system.
In 1995, Avlok was founded as the exclusive distributor for AVI International® products in North America. As a globally recognized leader in high-pressure solutions, AVI International manufactures components and systems for a variety of high-pressure applications. Our knowledgeable team of engineers and customer service representatives is here to assist you in choosing the best products for your needs.
At Avlok, we offer a wide range of high-pressure fittings that can be shipped the next day or even the same day. These fittings are essential for completing high-pressure liquid and gas systems, serving as critical components that ensure safety and reliability. Remember, a system’s strength is determined by its weakest parts. With Avlok’s application engineering support, you can be confident that the right fittings are selected to meet the pressure, flow, and duty specifications required by your entire system.
Enquiry
If you have any query related to this product please contact us at +912222821251 or reach to us through email at info@avlok.com. Our experts would guide you the same and inform regarding other various metals suitable for your applications.
FAQ
High-pressure fittings are specialized tube, pipe, or hose connecting components used in systems that operate at high pressures. They are designed to withstand extreme pressure and prevent leakage or failure, making the system safe and reliable.
The most common fittings used for high pressure are those materials known for strength, durability, and a high resistance to corrosion. Most of these are stainless steel, carbon steel, and assorted forms of alloy steels. The choice of the material is based on the exact application and environmental factors, which include temperature and exposure to chemicals.
The pressure rating of high-pressure fittings varies based on their design and material, ranging from several thousand psi (pounds per square inch) to tens of thousands psi. Always refer to the manufacturer’s specifications for the exact pressure rating to ensure the fitting is appropriate for your application.
